About Oxygen
At NF, we are dedicated to improving and transforming the environment with eco-friendly products.
What is the NF Wellness Oxygen Supply System?
The NF Wellness Oxygen Supply System draws in air, separates the oxygen from nitrogen, and filters the oxygen
through a three-stage filtration system, including an antimicrobial filter. The purified oxygen is then delivered
indoors, creating a refreshing, forest-like atmosphere in any space.
- Air Intake
- The system draws in air through an outdoor oxygen generator.
- Air Separation
- The filtered air passes through a module that separates oxygen from nitrogen.
- Oxygen Supply
- The purified oxygen is then diffused into the room through indoor diffusers.
1Air Intake
The system draws in air through an outdoor oxygen generator.
2Air Separation
The filtered air passes through a module that separates oxygen from nitrogen.
3Oxygen Supply
The purified oxygen is then diffused into the room through indoor diffusers.
Oxygen Supply System Configuration
Similar to an air conditioning system, the oxygen generator is installed outdoors or in a separate area,
while oxygen is supplied to living spaces like bedrooms and living rooms via oxygen diffusers.
- 1. Room Controller
- 2. Ceiling-Mounted Diffuser
- 3. Wall-Mounted Diffuser
- 4. Standalone
Diffuser
- 5. Oxygen Generator
How the NF Oxygen Supply System Works
Step 1 External Air Filtration
The air goes through a four-stage filtration process to remove impurities and bacteria, ensuring the supply of clean oxygen.
- 1 Pre-Filter
- Removes large dust particles and pollutants during the initial filtration.
- 2 HEPA Filter
- Filters out fine dust and viruses.
- 3 Antimicrobial Filter
- Targets bacteria like E. coli and Staphylococcus.
- 4 Bacteria Filter
- Eliminates bacteria from the air in the final filtration stage.
Antibacterial Hyperbranched Polymer and Spherical Activated Carbon Using It
A specialized technology for antibacterial treatment of harmful substances in the air. This applies an antibacterial, hyperbranched polymer-based spherical activated carbon with a 3D structure enhanced with silver (Ag) for improved strength.
Step 2 Oxygen Extraction
The filtered air passes through a zeolite filter to separate oxygen from nitrogen.
2-1 Zeolite Filtration
Zeolite is a porous crystalline structure that selectively extracts nitrogen from the air, allowing oxygen to be separated.
2-2 Separation of Oxygen and Nitrogen
Step 3 Oxygen Supply
High-purity oxygen, separated from nitrogen, is delivered through oxygen supply pipes and diffused into the space.
Custom Installation for Various Living Spaces: Transform Your Daily Life into a Forest-Like Environment
- Living Room
- As a common space for relaxation, the living room requires ongoing ventilation and air quality management due to household dust and pollutants. By adding oxygen, you can create a fresh, comfortable indoor environment without the need for constant ventilation.
- Bedroom
- With an average of six hours spent sleeping each night, carbon dioxide can accumulate in the bedroom. Supplying oxygen to this space ensures a restful and refreshing sleep. A well-oxygenated environment helps relax the body and mind, promoting deep sleep and aiding in the improvement of insomnia and other sleep disorders.
- Study / Children’s Room
- Provide clean oxygen to environments where long periods of focus are required without much physical movement. An oxygen-rich environment enhances oxygen intake, improving concentration and performance.
Certified as a medical device manufacturer and holder of domestic and international patents for oxygen generator technology.
■ Oxygen Supply System Apparatus For Hospital Patent No. 10-1117356
■ Oxygen Generation System Patent No. 10-1313924
■ Purifying Apparatus Using Photocatalytic Sheet US.10758893.B2
■ Replaceable Apparatus for Generating Oxygen with Independent Adsorption Module Patent No. 10-1954961
■ High Efficiency Oxygen Generator of Twin Tower Type Patent No. 10-1353198
